Electrical Characteristics

Power Supply: Battery (Rechargeable)

Operating Voltage Range: DC 3.4V - 4.5V

Operating Current: 4V/Average 35mA

Sleep Current: 4V/<5mA

Built-in Battery Capacity: 10,000 mAh (3.7V polymer battery)

Environmental Characteristics

Operating Temperature Range: -20°C - 75°C

Storage Temperature Range: -30°C - 80°C

Operating Humidity Range: 10%-85% RH (non-condensing)

Communication Characteristics

Communication Module Brand/Chip Model: QUECTEL MC25

Communication Frequency Band: 850/900/1800/1900MHz

SIM Card: Micro SIM Card

Communication Antenna: Built-in

GPS/BD Positioning Characteristics

Positioning Module Brand/Chip Model: Zhongkewei AT6558R

Positioning Method: Beidou + GPS

Cold Start Time: Average 32 seconds

Hot Start Time: Average 1 second

Sensitivity (Tracking): -162 dBm

Positioning Antenna: Built-in

External Interface

Light Sensor: Built-in light sensor

USB: 5V charging port

Specifications

Device Dimensions (L/W/H): 112mm * 78mm * 27mm

Casing Material: ABS Plastic

IP Rating: IP67

Magnets: 6 NdFeB permanent magnets (18mm * 2.8mm)

Device Weight: 300.5g

Soin’s fleet vehicle GPS tracker devices are designed for logistics fleets, rental vehicles, and corporate car systems. With strong durability, intelligent features, and customizable OEM options, it empowers businesses to reduce loss, improve efficiency, and strengthen operational control.
