Electrical Characteristics

Power Supply: Battery

Operating Voltage Range: DC 9V - 95V

Operating Current: 12V/Average 35mA

Sleep Current: 12V/<10mA

Built-in Battery Capacity: 80mAh (3.7V polymer battery)

Environmental Characteristics

Operating Temperature Range: -30°C - 75°C

Storage Temperature Range: -30°C - 80°C

Operating Humidity Range: 10%-85% RH (non-condensing)

Communication Characteristics

Communication Module Brand/Chip Model: QUECTEL MC25

Communication Frequency Bands: Supports 2G: 850/900/1800/1900MHz

SIM Card: Micro SIM Card

Communication Antenna: Built-in

GPS/BD Positioning Characteristics

Positioning Module Brand/Chip Model: Zhongkewei AT6558R

Cold Start Time: Average 32 seconds

Hot Start Time: Average 1 second

Sensitivity (Tracking): -162 dBm

Location Antenna: Built-in

External Interface

I/O Ports: Low-Power Output (1 for fuel and power failure)

High-Power Input (1 for ACC detection)

Appearance

Dimensions: 77mm * 28mm * 15mm

Casing Material: ABS Plastic

Main Unit Weight: 32g
